COP-USA CC35NVD 520 Line Resolution Day/Night C/CS Mount Security Camera
|
CC35NVD Overview:
Sometimes a security camera comes along that just blows the competition away. The COP-USA CC35NVD is one of those cameras. With an incredible 52+dB of S/N ration, and 520 lines (no kidding) of resolution, the CC35NVD cctv camera produces one of the finest pictures we have seen yet in a c/cs mount style cctv security camera.
Add to this a day/night feature which allows use in some of the lowest lighting conditions, this C/CS camera is the perfect choice for cctv security professionals and novices alike.
Call 231-932-9550 if you have questions about this.
.jpg)
.jpg)
CC35NVD Features:
■ 520TV Lines Resolution
■ Day/Night Function
■ Over 52dB Signal To Noise
■ Dual Voltage 12VDC & 24VAC
■ Audio Capabilities
CC35NVD Specifications:
|
Image Sensor: |
1/3" Sony Color
CCD |
|
Picture Elements: |
EIA/NTSC: 816H x 495 V - CCIR/PAL: 798 H x 584 V |
|
Horizontal Frequency: |
EIA//NTSC: 15.734 KHZ - CCIR/PAL: 15.625 KHZ |
|
Vertical Frequency: |
EIA//NTSC: 60 HZ - CCIR/PAL: 50 HZ |
|
Clock Frequency: |
EIA//NTSC: 19.0699 MHZ - CCIR/PAL: 18.9375 MHZ |
|
Audio: |
Yes |
|
Scanning System: |
2:1 interlace |
|
Horizontal Resolution: |
520 TVL |
|
Minimum Illumination: |
0.1 Lux Day & Night IR Sensitive |
|
Electronic Shutter
Speed: |
EIA//NTSC: 1/60 ~ 1/100.000sec - CCIR/PAL: 1/50 ~ 1/100.000sec |
|
Lens: |
3.6mm |
|
Auto Iris: |
Yes |
|
Video Output: |
1Vp-p , 75 Ohms |
|
Storage Temperature: |
-30°C ~ 60°C |
|
Operating Temperatures: |
-10°C ~ 45°C |
| Power Supply: |
Dual Voltage 12VDC & 24VAC |
| Functions: |
AGC, AWB, Video/ DC Drive |
| Power Consumption: |
150 mA |
|
